# High number of processes blocked in SQLServer
---

This incident type involves a high number of processes being blocked in SQLServer. It may cause delays or errors in database operations and can impact the performance of the system.

### Parameters
```shell
# Environment Variables

export SQLSERVER="PLACEHOLDER"

export SERVER_NAME="PLACEHOLDER"

export DATABASE_NAME="PLACEHOLDER"

export TABLE_NAME="PLACEHOLDER"

export PATH_TO_ERROR_LOG_FILE="PLACEHOLDER"



```

## Debug

### Next Step
```shell
powershell

# 1. Check the CPU usage of the SQLServer process.

Get-Process -Name ${SQLSERVER} | Select-Object -Property CPU
```

### 2. Check the memory usage of the SQLServer process.
```shell
Get-Process -Name ${SQLSERVER} | Select-Object -Property WorkingSet
```

### 3. Check the blocked processes in SQLServer.
```shell
Invoke-Sqlcmd -ServerInstance ${SERVER_NAME} -Database ${DATABASE_NAME} -Query "SELECT * FROM sys.dm_exec_requests WHERE blocking_session_id <> 0"
```

### 4. Check the top queries that are causing the blocking.
```shell
Invoke-Sqlcmd -ServerInstance ${SERVER_NAME} -Database ${DATABASE_NAME} -Query "SELECT TOP 10 * FROM sys.dm_exec_query_stats CROSS APPLY sys.dm_exec_sql_text(plan_handle) WHERE execution_count > 0 AND last_execution_time > DATEADD(minute, -5, GETDATE()) ORDER BY total_worker_time DESC"
```

### 5. Check the current state of the SQLServer.
```shell
Get-Service -Name ${SQLSERVER}
```

### 6. Check the SQLServer error logs for any relevant messages.
```shell
Get-Content "${PATH_TO_ERROR_LOG_FILE}" | Select-String -Pattern "blocked", "error", "warning"
```

## Repair

### Define input parameters
```shell
DB_NAME=${DATABASE_NAME}

TABLE_NAME=${TABLE_NAME}
```

### Check for inefficient queries
```shell
echo "Checking for inefficient queries in ${DB_NAME}..."

inefficient_queries=$(sqlcmd -S ${SERVER_NAME} -U ${USERNAME} -P ${PASSWORD} -d ${DB_NAME} -Q "SELECT query FROM sys.dm_exec_query_stats CROSS APPLY sys.dm_exec_sql_text(plan_handle) WHERE text LIKE '%${TABLE_NAME}%' ORDER BY total_worker_time DESC")

if [[ -z "${inefficient_queries}" ]]; then

    echo "No inefficient queries found."

else

    echo "Inefficient queries found:"

    echo "${inefficient_queries}"

fi
```

### Kill any long-running or blocking processes manually or automatically using a script.
```shell

# Define variables
 USERNAME="PLACEHOLDER"
 PASSWORD="PLACEHOLDER"
 SERVERINSTANCE="PLACEHOLDER"


# Define the query to find long-running or blocking processes

$Query = "SELECT session_id, status, blocking_session_id, wait_type, wait_time, wait_resource, command, last_wait_type, cpu_time, total_elapsed_time FROM sys.dm_exec_sessions WHERE is_user_process = 1 AND (status = 'running' OR blocking_session_id <> 0)"



# Get the list of processes to kill

$Processes = Invoke-Sqlcmd -Query $Query -ServerInstance ${SERVERINSTANCE} -Database ${DATABASE}



# Loop through the processes and kill them

ForEach ($Process in $Processes) {

    Write-Host "Killing process ID $($Process.session_id)..."

    Invoke-Sqlcmd -Query "KILL $($Process.session_id)" -ServerInstance ${SERVERINSTANCE} -Database ${DATABASE}

}



# Print a message to indicate completion

Write-Host "All long-running or blocking processes have been killed."


```

### Check the database for inefficiencies in queries or indexes that could potentially cause blocking. Optimize the queries or add indexes to improve performance.
```shell


# Define variables
 USERNAME="PLACEHOLDER"
 PASSWORD="PLACEHOLDER"
 SERVERINSTANCE="PLACEHOLDER"
 COLUMN_NAME="PLACEHOLDER"
 INDEX_NAME="PLACEHOLDER"



# Check for inefficiencies in queries or indexes

sqlcmd -S $SERVERINSTANCE -d ${DATABASE_NAME} -U $USERNAME -P $PASSWORD -Q "SET NOCOUNT ON; SELECT TOP 10 * FROM sys.dm_exec_requests"

sqlcmd -S $SERVERINSTANCE -d ${DATABASE_NAME} -U $USERNAME -P $PASSWORD -Q "SET NOCOUNT ON; SELECT TOP 10 * FROM sys.dm_exec_sessions"

sqlcmd -S $SERVERINSTANCE -d ${DATABASE_NAME} -U $USERNAME -P $PASSWORD -Q "SET NOCOUNT ON; SELECT TOP 10 * FROM sys.dm_exec_query_stats"



# Optimize queries or add indexes

sqlcmd -S $SERVERINSTANCE -d $database_name -U $USERNAME -P $databasePASSWORD_password -Q "SET NOCOUNT ON; EXEC sp_helpindex '${TABLE_NAME}'"

sqlcmd -S $SERVERINSTANCE -d $database_name -U $USERNAME -P $PASSWORD -Q "SET NOCOUNT ON; CREATE INDEX ${INDEX_NAME} ON ${TABLE_NAME} (${COLUMN_NAME})"



# Exit script

exit 0


```
